Components
1、Application range:Intersection safe protection in main area
2、Material: A3 Steel
3、Surface treatment : Paint with reflective strip
4、IP rate : IP67
5、Specified color:Black and yellow
6、Length: Customized
7、Width  ：520mm
8、Height:   70～90mm
9、Max loading weight: 80T
10、Spike Height :  150mm
11、Spike Thickness: 10mm
12、Drive mode: Electromechanical
13、Working Environment :   -40℃～+70℃
14、Control mode :Short range wireless remote control/drive-by-wire
15、Control distance ≤100M
16、Remote control distance: within 50M
17、Traffic light interface
18、Gang control with parking barrier
19、Material thickness：12mm
20、The whole plate forming bending, no welding

Technical Parameter
1、System ：220V electric drive
2、Passing pressure：Max 80T container truck
3、Power supply：220（Control voltage 24V）。
4、System dynamic power (w)：180W。
5、Rising time：≤1-2S
6、Lowering time：≤1-2S
7、Working Temperature：-35℃~75℃
8、Storage Environment ：-10℃~65℃
9、Material：A3 steel,with anti-rust paint
10、Color： Optional
11、Weight：0.3T
12、Casing Spec:Standard casing（Size can be customized）
L3000*W520*H70, Rising Length：150
L3500*W520*H70, Rising Length：150
L4000*W520*H70, Rising Length：150
L4500*W520*H70, Rising Length：150
L5000*W520*H70, Rising Length：150
L5500*W520*H70, Rising Length：150
L6000*W520*H70, Rising Length：150
